DIN Rail Kilowatt Hour Meter
Kilowatt Hour Meter(DS977 Series DIN-RAIL Energy meter)SPECIFICATION:mounting: DIN rail EN 5002designation: Rating(Amps) single phase 4 module 2.5(10)A ...three phases 7 module CT type 1.5(10)A...StandardIEC61036M......
Send Inquiry
Product Description
Kilowatt Hour Meter(DS977 Series DIN-RAIL Energy meter)
SPECIFICATION:
mounting: DIN rail EN 5002
designation: Rating(Amps)
single phase 4 module 2.5(10)A ...
three phases 7 module CT type 1.5(10)A...
SPECIFICATION:
mounting: DIN rail EN 5002
designation: Rating(Amps)
single phase 4 module 2.5(10)A ...
three phases 7 module CT type 1.5(10)A...
| Standard | IEC61036 |
| Model | DS977 Series |
| Accuracy | class 1.2 |
| Rated Current (A) | 2.5(10),3(15),5(30),10(50), 15(90), 20(100), 3*30(100) |
| Rated Voltage (V) | Single Phase:220~240V, Three Phase: 3*100V, 3*380V |
| Rated Impulse Voltage | Uimp:10kV-1.2/50μS |
| Power consumption | ≥2w/10VA per phase |
| TemperatureRange | -10ºC~+50ºC |
