Dds-5 Series DIN Rial Mounted Single Phase Electronic Energy Meter

Product Description

Product Information

Product Name	Dds-5 Series DIN Rial Mounted Single Phase Electronic Energy Meter
Measurement accuracy	Voltage: 0.5 level Ammeter:0.5 level Active power:0.5 level Reactive power:0.5 level Power factor:0.5 level Frequency:±0.02Hz Active power:0.5Sl evel/0.2S level Reactive power:1 level/2 level
Signal input	2.1 Connection mode: Single-phase 2.2 Rated voltage: AC 57.7. AC 100V. AC 220V. DC380V. Rated Electric current:AC 1A ; AC 5A 2.3 Overload: 1.2 times (Continued) 2times/1s (instantaneous) 1.2 times(Continued)10times/5s(insantaneous) 2.4 Power waste: <1VA/mutually 2.5 Impedance: >300KΩ 2.6 Frequency 45~65Hz/DC
Auxiliary power supply	3.1 Scope of work AV/DC 80V-270V. 3.2 Power waste <4VA; 4. Functional module 4.1 Communication interface: 1 road RS-485communication Modbus-RTUAgreement baud rate: 1200-9600bus,default2400bus 4.2.Switch input: Support 4 route dry node input 4.3. Switch output: Support 3 road relay output. capacity:AC 250V/5A ,DC 30V5A 4.4. Converter output: Support 1 way analog output:0/4~20mA or 0~5/10v Converter output: Support 2 way analog output:constant: 8000imp/kwh(kvarh)

Q1: Can I get a sample for testing?
A: Yes, we could offer free sample, but shipping cost should be paid at customers' side .
Q2: Can I print my logo on the products?
A: Yes, OEM and ODM are available.
Q3: How can I get the after-service?
A: If quality problem happen we promise re-send the item .
Q4: Do you have inspection procedures for products?
A: Our products100% self-inspection and testing before packing.
Q5: How about delivery time of the order?
A: 15-20 days after getting deposit.
Q6: How about payment terms?
A: 30% deposit, the rest payment balance against B/L copy
