Multi Jet Rotary Vane Wheel Vertical Water Meter
APPLICATIONThis range of water meter is used to measure the total quantity of cold potable water which consumed in houshold or a resident unit, passing through the pipeline.FEATURESThis is a dry-type water meter. Its counting and measuring devices are driven by magnetic coupling. It is characterized......
Send Inquiry
Product Description
APPLICATION
This range of water meter is used to measure the total quantity of cold potable water which consumed in houshold or a resident unit, passing through the pipeline.
FEATURES
This is a dry-type water meter. Its counting and measuring devices are driven by magnetic coupling. It is characterized by easy reading, good antifreezing property and ability to permanently keep the reading clear.
WORKING CONDITION
Water temperature ≤ 40º C Water pressure ≤ 1MPa
COMPLIANCE WITH STANDARD: ISO 4064 (GB/T778-1996)
INDICATING ERROR
At low zone is± 5% from minimum flow rate(qmin)to transitional flow rate(qt)exclusive boundary
At high zone is± 2% from transitional flow rate(qt) to overload flow rate(QS).
This range of water meter is used to measure the total quantity of cold potable water which consumed in houshold or a resident unit, passing through the pipeline.
FEATURES
This is a dry-type water meter. Its counting and measuring devices are driven by magnetic coupling. It is characterized by easy reading, good antifreezing property and ability to permanently keep the reading clear.
WORKING CONDITION
Water temperature ≤ 40º C Water pressure ≤ 1MPa
COMPLIANCE WITH STANDARD: ISO 4064 (GB/T778-1996)
INDICATING ERROR
At low zone is± 5% from minimum flow rate(qmin)to transitional flow rate(qt)exclusive boundary
At high zone is± 2% from transitional flow rate(qt) to overload flow rate(QS).
