Fmc Series Pd Rotary Vane Flow Meter
FMC Series PD Rotary Vane Flow MeterAdvantage:FMC series PD rotary vane meters are single case, angle-type, rotary vane, positive displacement meters.Superior accuracy and a wide range of products from gasoline to kerosene to fuel oils can be metered.Compact, versatile design can be readily fit into......
Send Inquiry
Product Description
Advantage:
FMC series PD rotary vane meters are single case, angle-type, rotary vane, positive displacement meters.
Superior accuracy and a wide range of products from gasoline to kerosene to fuel oils can be metered.
Compact, versatile design can be readily fit into nearly all installations.
Low pressure drop meter results in low meter slippage and thus superior meter accuracy.
Long service life, low friction ball bearings, fixed cam-type timing, and rugged construction give sustained accuracy and long time operation.
Application includes: blending, batching, dispensing, inventory control, and custody transfer of oils, solvents, chemicals, paints, fats and fertilizers.
| Technical specification | |||
| Model | FMC-50 | FMC-80 | FMC-100 |
| Size | 50mm/2" | 80mm/3" | 100mm/4" |
| Flow range | 38-380 L/min | 75-750 L/min | 150-1500L/min |
| Max.pressure | 10 Bar/150PSI | ||
| Accuracy | +-0.2% | ||
| Repeatability | 0.07% | ||
| Standard measurement | Unit liter / US gallon / Imperial gallon | ||
| Meter body | Aluminum,Cast iron,Steel,stainless steel available | ||
FAQ
1.What is MOQ?
usually one set,and we can delivery by fast air express which not occupy space and not heavy for transport
2.Can you also OEM OR ODM for us?
Yes,we customize logo and brand according to customer requirement.
3.How about your machine quality, we are worry about the quality?
We are more than 30 years manufacturing experience of different kinds of flow meters.We strictly manufacture and manage according to IOS9001:2000 System.and can match all the CE standard or more strict standard.our machines are running well in more than 30 countries
