Home > Products > Geographic Surveying Instrument > Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    • Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    • Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    • Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price

    Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price

    TELESCOPELength215mm (8.46 in.)Magnification28XObjective Aperture42mm (1.65 in.)Resolving Power3 in.Field of View(at 100m/328ft.)1°20' (2.3m/7.5 ft.)Min. Focus from end of telescope0.2m (7.9 in.)Min. Focus from instrument center0.3m (1 ft.)ImageErectStadia Constant0Stadia Ratio100Focusin......

    Send Inquiry

    Product Description

    Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    TELESCOPE
    Length215mm (8.46 in.)
    Magnification28X
    Objective Aperture42mm (1.65 in.)
    Resolving Power3 in.
    Field of View(at 100m/328ft.)1°20' (2.3m/7.5 ft.)
    Min. Focus from end of telescope0.2m (7.9 in.)
    Min. Focus from instrument center0.3m (1 ft.)
    ImageErect
    Stadia Constant0
    Stadia Ratio100
    Focusing Knob2-speed
    Sighting AidPeep Sight
    ACCURACY
    Without Micrometer0.7mm (0.03 in.)
    With Micrometer0.5mm (0.02 in.)
    COMPENSATOR
    TypePendulum compensator with magnetic damping system
    Setting Accuracy0.5 in.
    Working Range±15 ft.
    CIRCULAR LEVEL
    Sensitivity10 ft./2mm
    HORIZONTAL CIRCLE
    Diameter103mm (4.1 in.)
    Minimum Division1°/1gon
    GENERAL
    Water ResistanceIPX6 (IEC 60529:2001)
    Operating Temperature-4°F to +122°F (-20ºC to +50ºC)
    Width5.12 in. (130mm)
    Length8.46 in. (215mm)
    Height5.51 in. (140mm)
    Weight4.1 lbs. (1.85kg)


    Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
    Setting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level PriceSetting Accuracy 0.5in Topcon Automatic Level Machine at-B2/at-B3/at-B4 Dumpy Level Price
