China High Precision Rotary Laser Level Surveying Instrument (SRE-2010)

Product Description

Rotary Laser Level SRE-2010 Automatic leveling

Features of Rotary Laser Level SRE-2010:

Electronic auto-Leveling rotary laser level, Wide Leveling Range, High Precision and Stability.

With MCU Control, Completely Function, Easy Operation and High Reliability.

Vertical Setting The Unit, Supply a Horizontal Plane and Vertical Line, With Plumb Point.

Lay-Down Jobs, Supply a Vertical Plane and a Horizontal Line.

With Scanning Function.

With Clockwise and Counterclockwise Rotating Function.

With Setting Slope Dual Axis.

Good Waterproof.

With Remote Control of 360 Degree.

With Automatic Drift System Model

Specifications of Rotary Laser Level SRE-2010:
* Level System: Electronic sensor fast leveling
* Accuracy: 15 arc seconds(+/-0.75mm/10m)
* Self-leveling range: ± 5°
* Operation Rang: 500m with detector(Diameter)
* Four head speeds: 0; 60; 120; 300; 600 R. P. M.
* Four scan widths: 0° ; 10° ; 45° ; 90° ; 180°
* Wavelength: 635nm Class II
* Down Point Precision: ± 1mm/1.5m
* Remote Control working distance: 20m
* Operation Temperature: -20º C~+50º C(-4° F~+122° F)
* Power Supply: DC 4.8-6V(4*Sub-C Ni-MH Battery)
* Continuous working time: Approx. 50hr
* Waterproof: IP 55
* Dimension: 160(L) X 160(W)X 185(H)mm
* Weight: 2.7kg

Pictures of Rotary Laser Level SRE-2010:
High Precision Rotary Laser Level Surveying Instrument (SRE-2010)
